The T50 Tank Container offered by Big Mex Trailers is the benchmark for safe and efficient transportation of liquefied gases under pressure. Engineered to meet rigorous international standards, this container ensures reliability in industries where precision and safety are non-negotiable.

Specifications:

• External Dimensions:
  L 6.0 m × W 2.4 m × H 2.6 m (20’ × 8’ × 8’5”)
• Nominal Capacity:
  24,600 Liters
• Tare Weight:
  7,500 kg (16,535 lbs)
• Max Gross Mass:
  36,000 kg (79,365 lbs)
• Design Temperature Range:
  -40°C to +55°C (−67°F to +176°F)
• Working Pressure:
  18 Bar (261 psi)

Construction:

• High-grade stainless steel inner vessel for maximum corrosion resistance
• Rugged steel frame for structural integrity and transport safety
• Weather-resistant exterior suitable for all environments

Equipped With:

• Manlid access
• Safety relief valve
• Gas line and liquid line assemblies
• Pressure gauge and thermometer
• Level gauge for operational accuracy

Applications:
Ideal for industries such as oil and gas, chemical processing, and energy production, the T50 Tank Container is specifically designed for the bulk transport and storage of propane and other Class 2 gases within controlled pressure ranges.
